中船永志YZE－XDD系列吸頂燈，外形輕巧、造型經典，外殼采用乳白色進口聚碳酸酯注塑而成，透光性能優異；光源模塊化均勻分布，光亮度好，無暗區，能提供完整的日常室內照明。
Zhongchuanyongzhi YZE－XDD series Ceiling Lamp is of light weight and classic shape. The lamp housing is shaped by ivory imported polycarbonate through injection molding process, and it has excellent transparent property. The light source uses modular design, and has the characteristics of good lightness and no dark space. The series can provide normal indoor lighting service.
【產品特點】
[Product Characteristics]
◆ 綠色環保，不含鉛、汞等污染元素，材料可回收使用；
◆ Environment friendly, no lead, mercury or other elements of environmental pollution, recyclable.
◆ 采用進口LED芯片，高效穩定、節能效果明顯；
Using imported LED chip, high-efficiency, high stability and excellent energy-saving effect.
◆ 本公司自主研發的專用恒流驅動電源，無頻閃、無輻射，功耗極低，經久耐用；
Constant Current LED Power Supply developed by our company own, has the properties of flicker free, radiation free, low consumption and long service life.
◆乳白色亞克力面光源技術，光照均勻；
It adopts ivory acrylic coating and therefore ensures the light radiating evenly;
◆ 熱阻值小,芯片結溫可控制在60℃以下；
◆ With a small thermal resistance, the chip junction temperature can be controlled below 60 ℃.
◆ 燈具芯片壽命長達50000小時以上，為傳統燈具5－10倍
The service life of the chip can reach 50,000 hours, 5-10 times longer than traditional lamps.
◆ 顯色性好，顏色呈現更真實更鮮艷；多種色溫色相可選、發光角度可定制，滿足不同場合照明要求；
◆Its excellent color rendering property makes the light color feel more credible and more brightly; various color temperatures are available for your option; viewing angle can be customized to satisfy various lighting needs.
◆ 外觀輕薄，安全可靠，耐沖擊、耐腐蝕、抗震力強；
◆ The series has the following characteristic: light weight, low drag coefficient, dust proof, water proof, security and reliability, impact resistance, corrosion resistance and shock resistance；
◆ 無燈泡燈絲，全無傳統頻繁更換光源之憂；
◆Without light bulb and filament, it avoids the traditional problems caused by changing light source frequently.
|
型號
Model |
YZE-XDD-9 |
YZE-XDD-18 |
YZE-XDD-24 |
YZE-XDD-36 |
YZE-XDD-75 |
YZE-XDD-120 |
|
功率（W）Power (W) |
9 |
18 |
24 |
36 |
75 |
120 |
|
使用壽命(H)
Service Life (H) |
50000 |
50000 |
50000 |
50000 |
50000 |
50000 |
|
色溫（K）
Color Temperature (K) |
2700-8000 |
2700-8000 |
2700-8000 |
2700-8000 |
2700-8000 |
2700-8000 |
|
發光效率（lm/W）
Luminous Efficiency（lm/W） |
100 |
100 |
100 |
100 |
100 |
100 |
|
電源效率（%）
Power Efficiency（%） |
≥85 |
≥85 |
≥85 |
≥85 |
≥85 |
≥85 |
|
功率因素
Power Factor |
0.9 |
0.9 |
0.9 |
0.9 |
0.9 |
0.9 |
|
顯色指數Ra
Color Rendering Index Ra |
≥80 |
≥80 |
≥80 |
≥80 |
≥80 |
≥80 |
|
初始光通量（lm）
LED Initial Flux（lm） |
900 |
1800 |
2400 |
3600 |
7500 |
12000 |
|
額定工作電壓
Rate voltage |
220V/50Hz |
220V/50Hz |
220V/50Hz |
220V/50Hz |
220V/50Hz |
220V/50Hz |
◆機場、車站、寫字樓、賓館、體育場、停車場、家居等廣泛的室內照明；
A wide range of Indoor illumination applications, such as office building, hotel, shopping mall, exhibition hall, bar, house, etc.
□銀灰色 □白色 □鍍鎳 □鐵黑色（提供多種色彩、造型外觀可選）
□Silver Grey □White □Nickel Plated □Iron Oxide Black（various colors and shapes are available）
